Fuse Finder


Purpose	Panel Location	fuse location	rate	note
Electric Toilet	Bay 2 DC box	Module C Ch 10	7.5a	J4-4
Kitchen aisle Lights	Bay 2 DC box	Module C Ch 9	7.5a	J4-3
Toilet Closet Cir	Bay 2 DC box	Module C Ch 8	7.5a	J4-2
Br Tol Lt	Bay 2 DC box	Module C Ch 7	7.5a	J4-1
Fr 12V Receptical	Bay 2 DC box	Module C Ch 6	10a	J1-6
CO2 Detector	Bay 2 DC box	Module C Ch 5	7.5a	J1-5
Entry Door Light	Bay 2 DC box	Module C Ch 4	7.5a	J1-4
Bed Room 12V receptical	Bay 2 DC box	Module C Ch 3	10a	J1-3
Refrigerator	Bay 2 DC box	Module C Ch 2	10a	J1-2
Dining room 12V receptical	Bay 2 DC box	Module C Ch 1	10a	J1-1
Living Room Ceiling	Bay 2 DC box	Module B Ch 1	10a	J1-1
Dining Room Ceiling Light	Bay 2 DC box	Module B Ch 2	10a	J1-2
Bath Ceiling Light	Bay 2 DC box	Module B Ch 3	10a	J1-3
Bed Room Celing Lights 1	Bay 2 DC box	Module B Ch 4	7.5a	J1-4
Bed Room Celing Lights 2	Bay 2 DC box	Module B Ch 5	7.5a	J1-5
Kitchen Celing Lights	Bay 2 DC box	Module B Ch 6	10a	J1-6
Kitchen Spotter Lights	Bay 2 DC box	Module B Ch 7	10a	J4-1
Living Room Spotter Light	Bay 2 DC box	Module B Ch 8	7.5a	J4-2
Bed Room Celing Lights	Bay 2 DC box	Module B Ch 9	10a	J4-3
Toilet Closet Celing Lights	Bay 2 DC box	Module B Ch 10	10a	J4-4
Bed Room Celing Vista	Bay 2 DC box	Module D Ch 1	7.5a	J2-1
Bed Room Aisle Lights	Bay 2 DC box	Module D Ch 2	7.5a	J2-2
PR tol Spotter Lights	Bay 2 DC box	Module D Ch 3	7.5a	J2-3
Bath Room Celing Vista Lights	Bay 2 DC box	Module D Ch 4	7.5a	J2-4
Bath Room Vanity Spotter Lights	Bay 2 DC box	Module D Ch 5	7.5a	J2-5
Bath Room Aisle Lights	Bay 2 DC box	Module D Ch 6	7.5a	J2-6
Dining Room Spotter Lights	Bay 2 DC box	Module D Ch 7	7.5a	J3-1
Living Room Spotter Lights	Bay 2 DC box	Module D Ch 8	7.5a	J3-2
Bedroom Window Vista Lightrs Left Hand	Bay 2 DC box	Module D Ch 9	7.5a	J3-3
Washer Dryer Closet Lights	Bay 2 DC box	Module D Ch 10	7.5a	J3-4
Power Cord Reel Reelmaster	Bay 2 DC box	Module G Ch 1	15a	J2-1 **note other fuse on 12v house block to right
Power Cord Reel Reelmaster	Bay 2 DC Box	12V House block	15a	mid cabinet to right; block of resettables bottom fuse right row ** Note other fuse modG ch1
Power Cord Reel RELAY	Bay 2 DC Box	32b		mid box find row of 6 relays maybe 5th from top
Water Hose Reel	Bay 2 DC box	Module G Ch 2	10a	J2-2
Bay 2 Heater	Bay 2 DC box	Module G Ch 3	7.5a	J2-3
Black Dump Valve	Bay 2 DC box	Module G Ch 4	7.5a	J2-4
Water Pump	Bay 2 DC box	Module G Ch 5	7.5a	J2-5
Grey Water Valve	Bay 2 DC box	Module G Ch 6	20a	J2-6
Fresh Water Fill Valve	Bay 2 DC box	Module G Ch 7	7.5a	J3-1
Bay 12V Receptical	Bay 2 DC box	Module G Ch 8	7.5a	J3-2
Bed Spotter Lights	Bay 2 DC box	Module G Ch 9	7.5a	J3-3
Bay 4 Heater	Bay 2 DC box	Module G Ch 10	7.5a	J3-4
Front Air Conditioner	Bay 2 DC box	Module E Ch 1	7.5a	J2-1
Bath Room Air Conditioner	Bay 2 DC box	Module E Ch 2	7.5a	J2-2
Toilet Closet Floor LT	Bay 2 DC box	Module E Ch 3	7.5a	J2-3
Dining Room Kitchen Vista	Bay 2 DC box	Module E Ch 4	7.5a	J2-4
Porch Light Cir	Bay 2 DC box	Module E Ch 5	7.5a	J2-5
Bedroom Window Vista Light Left	Bay 2 DC box	Module E Ch 6	7.5a	J2-6
Propane Detector	Bay 2 DC box	Module E Ch 7	7.5a	J3-1
Tank Monitor	Bay 2 DC box	Module E Ch 8	7.5a	J3-2
Heater LR	Bay 2 DC box	Module E Ch 9	7.5a	J3-3
Heater Kitchen	Bay 2 DC box	Module E Ch 10	7.5a	J3-4
Shower Fan Relay	Bay 2 DC box	4 bosh relay group		Center top of box top of 4 relays
Toilet Closet Fan Relay	Bay 2 DC box	5 bosh relay group		Center topof box 2 down of 4 relays
Wabasto Heater Val Relay	Bay 2 DC box	6 bosh relay group		Center top of box 3 down of 4 relays
Engine Preheat Switch	Bay 2 DC box	7 bosh relay group		Center top of Box bottom of 4 relays
Compartment Lights	Bay 2 DC box	Module F Ch 1	20a	J2-1
Left Hand RR Landing Lights	Bay 2 DC box	Module F Ch 2	10a	J2-2
Left Hand Landing Lights	Bay 2 DC box	Module F Ch 3	15a	J2-3
Right Hand RR Landing Lights	Bay 2 DC box	Module F Ch 4	10a	J2-4
Right Hand Landing Lights	Bay 2 DC box	Module F Ch 5	15a	J2-5
Left Hand Porch Light	Bay 2 DC box	Module F Ch 6	7.5a	J2-6
Living Room Celing Vista Lights	Bay 2 DC box	Module F Ch 7	7.5a	J3-1
Heater Bathroom	Bay 2 DC box	Module F Ch 8	7.5a	J3-2
Heater Bed Room	Bay 2 DC box	Module F Ch 9	7.5a	J3-3
Heater Dash	Bay 2 DC box	Module F Ch 10	7.5a	J3-4
CPU 12V	Bay 2 DC box	12V HOUSE	10a	far right block of 8 fuses near a 24v block
Relays	Bay 2 DC box	12V HOUSE	10a	far right block of 8 fuses near a 24v block
EMS Load Center 1	Bay 2 DC box	12V HOUSE	10a	far right block of 8 fuses near a 24v block
EMS Load Center 2	Bay 2 DC box	12V HOUSE	10a	far right block of 8 fuses near a 24v block
EMS Load Center 2	Bay 2 DC box	12V HOUSE	10a	far right block of 8 fuses near a 24v block
Wabasto Heater	Bay 2 DC box	24V House	25a	far right block of 8 fuses near a 12v block
Wabasto Heater	Bay 2 DC box	24V House	25a	far right block of 8 fuses near a 12v block
Wabasto Heater RL SW 1	Bay 2 DC box	24V House	10a	far right block of 8 fuses near a 12v block
24 Volt Compartment Lock	Bay 2 DC box	24V House	10a	far right block of 8 fuses near a 12v block
Wabasto Heater Val	Bay 2 DC box	24V House	10a	far right block of 8 fuses near a 12v block
Inverter Fan	Bay 2 DC box	24V House	10a	far right block of 8 fuses near a 12v block
Mag Dr Sw	Behind Driver	Module A-1	10a
Not Used	Behind Driver	Module A-2	7.5a
Shade Module	Behind Driver	Module A-3	15a
Ignition	Behind Driver	Module A-4	7.5a
Not Used	Behind Driver	Module A-5	7.5a
Map Lights	Behind Driver	Module A-6	7.5a
Cell Phone	Behind Driver	Module A-7	10a
AV Fans and therm	Behind Driver	Module A-8	7.5a
12v air compressor	Behind Driver	Module A-9	15a
Map Lights	Behind Driver	Module A-10	7.5a
Audio Visual Power	Behind Driver	Module B-1	10a
RR View Mirrow	Behind Driver	Module B-2	7.5a
Cig Lighter	Behind Driver	Module B-3	10a
satellite antenna	Behind Driver	Module B-4	7.5a
step cover in	Behind Driver	Module B-5	7.5a
step cover out	Behind Driver	Module B-6	7.5a
Gen Logic power	Behind Driver	Module B-7	10a
Stepwell lights	Behind Driver	Module B-8	7.5a
Musical horn	Behind Driver	Module B-9	10a
step well cover supply	Behind Driver	Module B-10	7.5a
Co Pilot Passenger Seat	Behind Driver	ModuleC-1	20a
GPS ignition	Behind Driver	ModuleC-2	7.5a
Pilot Seat	Behind Driver	ModuleC-3	20a
Glc Power 3	Behind Driver	ModuleC-4	7.5a
Not used	Behind Driver	ModuleC-5	7.5a
Lugg Lk Supply	Behind Driver	ModuleC-6	7.5a
HSMSTR	Behind Driver	ModuleC-7	10a
Luggage door Lock Relay	Aux Air Bay	Relays		Block of four
Luggage door Unlock Relay	Aux Air Bay	Relays
Horn	Aux Air Bay	Relays
12V ignition	Aux Air Bay	Relays
Diag	Aux Air Bay	12v Batt1 top left	7.5a	fuse block to the left
Clr Lights	Aux Air Bay	12v Batt1	15a	fuse block to the left
drl	Aux Air Bay	12v Batt1	15a	fuse block to the left
Speedo	Aux Air Bay	12v Batt1	7.5a	fuse block to the left
Instrument	Aux Air Bay	12V IGN 10 Chassis	7.5a
Mirror	Aux Air Bay	12V IGN 10 Chassis	7.5a
Instrument	Aux Air Bay	12V IGN 10 Chassis	7.5a
Wipers	Aux Air Bay	12V IGN 10 Chassis	7.5a
Daytime running lights	Aux Air Bay	12V IGN 10 Chassis	7.5a
Instrument	Aux Air Bay	12V IGN 10 Chassis	7.5a
House	Aux Air Bay	12V IGN 10 Chassis	7.5a
B alarm	Aux Air Bay	12V IGN 10 Chassis	7.5a
Smart Wheel	Aux Air Bay	12V Batt 2 Chassis	15a
Clock	Aux Air Bay	12V Batt 2 Chassis	7.5a
LvL system	Aux Air Bay	12V Batt 2 Chassis	7.5a
Chassis	Aux Air Bay	12V Batt 2 Chassis	7.5a
Burglar Alarm	Aux Air Bay	12V Battery House	25a
Visor	Aux Air Bay	12V Battery House	15a
Gen Sld	Aux Air Bay	12V Battery House	15a
Burglar Alarm	Aux Air Bay	12V Battery House	25a
Step Poser	Aux Air Bay	12V Battery House	25a
Coach	Aux Air Bay	12V Battery House	7.5a
B Alarm	Aux Air Bay	12V Battery House	25a
D2 Pwr A	behind closet bed	24V Batt Chassis Midlevel road side	30 A
D2 Pwr B	behind closet bed	24V Batt Chassis Midlevel road side	15 A
Eng Pwr	behind closet bed	24V Batt Chassis Midlevel road side	30 A
336	behind closet bed	24V Batt Chassis Midlevel road side	10 A
D1 Input Com	behind closet bed	24V Batt Chassis Midlevel road side	7.5 A
D2 Input com	behind closet bed	24V Batt Chassis Midlevel road side	7.5 A
D3 Pwr	behind closet bed	24V Batt Chassis Midlevel road side	7.5 A
D1 Pwr A	behind closet bed	12V Batt Chassis Midlevel road side	30 A
ECL 12	behind closet bed	12V Batt Chassis Midlevel road side	15 A
ABS Batt	behind closet bed	12V Batt Chassis Midlevel road side	30 A
D1 Pwr B	behind closet bed	12V Batt Chassis Midlevel road side	15 A
Tail Lts	behind closet bed	12V Batt Chassis Midlevel road side	20 A
Stop Lts	behind closet bed	12V Batt Chassis Midlevel road side	20 A
Turn Its	behind closet bed	12V Batt Chassis Midlevel road side	20 A
Brake Lts	behind closet bed	12V Batt Chassis Midlevel road side	20 A
J170	behind closet bed	12V Batt Chassis Midlevel road side	10 A
146V26	behind closet bed	12V Batt Chassis Midlevel road side	10 A
ABS Ign	behind closet bed	12V Batt Chassis Midlevel road side	5 A
PRX Ign	behind closet bed	12V Batt Chassis Midlevel road side	10 A
12V Ign	behind closet bed	12V Batt Chassis Midlevel road side	15 A
DC Control AC Relays	behind closet bed	3000 Module	3 A
DC Control AC Relays	behind closet bed	3001 Module	5 A
HVAC Power	In dash forward of entry step	Right side wall	30 A
CAT Eng Display	In dash forward of entry step	Right side wall	7.5 A
Alternator sens 12 volt	Battery Bay	in rubber cover fuse holder near Engine cut off red wire
Slide	in 120v transformer box	white cb on the output
Slide	in air lockvalve cabinet	white cb style 27v
Slide	dc bay black top on left cabinet	c-card to the left most manages the safety prompts	3amp
Driver Seat	Under Cushion	hanging in a black holder blase fuse	5 amp
Slide	dc bay black top black cabinet	right most circuit card two blade fuses one card does fore motor other card does aft
Shade	Outside Below Driver window	power to spyder controller box right side spyder is labled	10 amp	In a rubbrt spade single holder
Step Relay		module A Fuse 6	7.5 amp	this is inter connected to the Map Light some way https://450lxi.com/index.php/discussions/another-entry-step-question
Back Up alarm Light	behind closet Bed	D1 Module Dinex F7	10a
Air Dryer	behind closet bed	D1 F5	10a
CS Turn signal relay	behind closet bed	D1 F4	10a
RS Turn signal Relay	behind closet bed	D1 F3	10a
Stop Light relay	behind closet bed	D1 F2	10a
Tail light relay	behind closet bed	D1 F1	10A
Rear Ignition	behind closet bed	D2 F7
Starter solenoid	behind closet bed	D2 F3
Fuel Heater	behind closet bed	D2 F1
ABS Traction control	behind closet bed	D3 F8
Shift enable	behind closet bed	D3 F7
Transmission Service Brake	behind closet bed	D3 F6
Fast Idle	behind closet bed	D3 F5
Engine Brake Med Hi	behind closet bed	D3 F4
Engine Brae Low HI	behind closet bed	D3 F3
Egine Service Brake	behind closet bed	D3 F2
Throttle Interlock	behind closet bed	D3 F1
Smart Wheel cruise wipers	Outside Below Driver window	3amp		this fuse controls one signal to those devices from smart wheel human input devise
Big Foot Stabilizers	GreyBox BatteryBay	house 12v	125 a	mega AMG fuse by itself issues are common with the negative
